Cement Rotary Drum Dryer for Limestone, Coal Ash, Slag
Key Specifications / Features
Model No.: RD-01 Hits: 81
Rotary drum dryer supplier in China with diameter 1.5 x 12M to 3.6 x 28M, max 80 - 120 T/D for limestone, 92 - 98 T/D for coal ash, 100 - 110 T/D for slag.
Request a quote
Share
Tags:
Detail Infomation
Main Spare Parts for Rotary Dryer:
Girth Gear & Pinion Unit, Kiln Tyre, Supporting Roller Assembly, Hydraulic Thrust Roller Device, Kiln Head & Tail Sealing Parts, Kiln Shell and Heat Resistant Castings.
Introduction:
High-efficiency rotary dryer is mainly used in building material industry for drying slag, clay and coal. The newly designed high-efficiency rotary dryer supplied by SINOSPARE can boost 10~15% production but save 10~15% energy by applying modified scatter plate devices, and materials can be fully dried by heat airflow system of scattering devices.
Features:
1. Good sealing performance
2. Flexible rotating speed
3. Easy installation and maintenance
4. Low vibration and high stability
Girth Gear & Pinion Unit, Kiln Tyre, Supporting Roller Assembly, Hydraulic Thrust Roller Device, Kiln Head & Tail Sealing Parts, Kiln Shell and Heat Resistant Castings.
Introduction:
High-efficiency rotary dryer is mainly used in building material industry for drying slag, clay and coal. The newly designed high-efficiency rotary dryer supplied by SINOSPARE can boost 10~15% production but save 10~15% energy by applying modified scatter plate devices, and materials can be fully dried by heat airflow system of scattering devices.
Features:
1. Good sealing performance
2. Flexible rotating speed
3. Easy installation and maintenance
4. Low vibration and high stability
| Specifications (m) |
∅1.5x12 | ∅2.2x14 | ∅2.4x18 | ∅3x20 | ∅3x25 | ∅3.2x25 | ∅3.6x28 | ||
| Ability (t/d) |
Limestone | 7~14 | 15~26 | 28~46 | 55~85 | 60~90 | 70~100 | 80~120 | |
| Pulverized Coal ash | 3~6 | 7~13 | 10~16 | 28~50 | 35~62 | 62~66 | 92~98 | ||
| Slag | 10~20 | 28~35 | 35~45 | 45~65 | 65~80 | 90~96 | 100~110 | ||
| Slope of machine shell(%) | 4 | 4 | 5 | 5 | 3 | 3 | 3 | ||
| Support quantity(pcs) | 2 | 2 | 2 | 2 | 2 | 2 | 2 | ||
| Type of stop wheel | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | ||
| Mechanical driving(r/min) | 8.4 | 8.4 | 4 | 5.6 | 5.6 | 3.9 | 3.6 | ||
| Main Driving |
Motor | Type | Y180L-6 | Y225M-6 | Y280S-6 | Y315S-6 | Y315M-6 | Y315L1-6 | Y315L2-6 |
| Rated power(KW) | 15 | 30 | 45 | 75 | 90 | 110 | 132 | ||
| Reducer | Type | JZQ650-VI-4F | JZQ650-VI-4F | JZQ850-ll-4F | ZSY315-22-ll | ZSY315-22-II | ZSY315-22-II | ZSY355-35 | |
| Total ratio | 15.75 | 15.75 | 31.5 | 16 | 22.4 | 22.4 | 35.5 | ||
| Type of scattering plate | Lifting type, Arc | New combined scattering plate | |||||||
| Total weight(t) | 22 | 30 | 45 | 68 | 80 | 90 | 125 | ||
