Custom Baghouse Cement Dust Collector
Key Specifications / Features
Model No.: DC-02 Hits: 50
Custom baghouse cement dust collector supplier in China provides custom baghouse dust collector for cement plant, easy operation and reliable quality.
Request a quote
Share
Tags:
Detail Infomation
The baghouse dust collector has a simple and reliable dust collecting method. The dust will be blown into baghouse dust collector from the bottom side and the clean air with required dust density content will be discharged into the air after filtration effects by the filter bags equipped in the dust collector.
The dust collector can create the air flow from dust gas to cleaned gas generated by fans with motor and air flow is under controlled and guided by the mechanical parts of the dust collector. The dust removed from collector can exert in the silo and fall on the belt conveyor directly. Dust on the filter bag increases gradually after the dust collector working for a period of time and the resistance of the filter bag rises which needs to proceed vibrating strike dust removing method.
FEATURES & BENEFITS
• Manual or Programmed Vibrating Strike Dust Removing
• Small Volume
• Strong Wind Power
• Compact Structure
• Easy Operation and Reliable Quality
APPLICATIONS
Bag Type Dust Collector is designed for dust cleaning of the silo top, silo bottom, material belt conveying system and the purposed dust collecting in exhausting points.
The dust collector can create the air flow from dust gas to cleaned gas generated by fans with motor and air flow is under controlled and guided by the mechanical parts of the dust collector. The dust removed from collector can exert in the silo and fall on the belt conveyor directly. Dust on the filter bag increases gradually after the dust collector working for a period of time and the resistance of the filter bag rises which needs to proceed vibrating strike dust removing method.
FEATURES & BENEFITS
• Manual or Programmed Vibrating Strike Dust Removing
• Small Volume
• Strong Wind Power
• Compact Structure
• Easy Operation and Reliable Quality
APPLICATIONS
Bag Type Dust Collector is designed for dust cleaning of the silo top, silo bottom, material belt conveying system and the purposed dust collecting in exhausting points.
| Technical Parameter of Bag Type Dust Collector | |||||||
| Type Performance | BT24 | BT32 | BT48 | BT56 | BT64 | BT64L | BT80 |
| Working Air Quantity (m3/h) | 1000 -2000 | 1500 -2000 | 2000 -3000 | 3000 -3400 | 3480 -4200 | 4200 -5200 | 5200 -6000 |
| Resistance of Dust Collector (Pa) | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 |
| Filter Area (m2) | 10 | 14.48 | 20 | 25 | 26 | 35 | 40 |
| Filter Speed (m/min) | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 |
| Collecting Efficiency (%) | ＞99.9 | ＞99.9 | ＞99.9 | ＞99.9 | ＞99.9 | ＞99.9 | ＞99.9 |
| Blower Power (KW) | 2.2 | 3 | 5.5 | 5.5 | 7.5 | 7.5 | 11 |
| Deashing Motor Power (KW) | 0.25 | 0.25 | 0.25 | 0.37 | 0.55 | 0.55 | 0.55 |
| Blower Motor No. | Y90L-2 | Y100L-2 | Y132S1-2 | Y132S1-2 | Y132S1-2 | Y160M2-2 | Y160M1-2 |
| Deashing Motor Power Type | Y801-4 | Y801-4 | Y801-4 | Y801-4 | Y801-4 | Y801-4 | Y801-4 |
