Cement Air Slide Conveyor
Key Specifications / Features
Model No.: SSP-03 Hits: 179
Cement air slide conveyor supplier in China provides customized cement air slide conveyor with low power consumption, for conveying dry powder media.
Request a quote
Share
Tags:
Detail Infomation
Air slide conveyor is a kind of pneumatic conveying equipment which is widely used to convey dry powder materials. Air slide conveyor is used to convey cement and raw material powder here in cement plant. It is widely used to charge and discharge powder materials at multi-points because is a kind of pneumatic conveying equipment without motor driving parts. The main part of air slide is ventilated fabric layer. Type PET-6 polyester compound fiber textile which is characterized by high-temperature resistance (150℃), anti-corrosion, anti-abrasion, low moisture absorption, lightweight, smooth surface and long service life.
FEATURES & BENEFITS
• First Class Quality
• Easy Maintenance
• Good Sealing
• No Noise
• Safe Operation
• Low Electric Consumption
• Convenient to Divert
APPLICATIONS
For conveying any bulk dry free-flowing powder from point to point
SPECIFICATION
FEATURES & BENEFITS
• First Class Quality
• Easy Maintenance
• Good Sealing
• No Noise
• Safe Operation
• Low Electric Consumption
• Convenient to Divert
APPLICATIONS
For conveying any bulk dry free-flowing powder from point to point
SPECIFICATION
| Technical Parameters of Air Slide Conveyor | ||||||||||
| Type | XZ200 | XZ250 | XZ315 | XZ400 | XZ500 | XZ630 | XZ800 | |||
| Groove Width | mm | 200 | 250 | 315 | 400 | 500 | 630 | 800 | ||
| Conveying Capacity | a=4° | Cement | T/h | 22 | 40 | 70 | 130 | 220 | 320 | 400 |
| Raw Material | 16 | 30 | 55 | 100 | 165 | 245 | 310 | |||
| a=6° | Cement | 40 | 65 | 120 | 250 | 400 | 610 | 765 | ||
| Raw Material | 30 | 55 | 90 | 185 | 300 | 455 | 565 | |||
| a=8° | Cement | 50 | 80 | 140 | 300 | 470 | 720 | 900 | ||
| Raw Material | 35 | 65 | 110 | 225 | 355 | 540 | 670 | |||
| a=10° | Cement | 60 | 100 | 170 | 380 | 570 | 900 | 1080 | ||
| Raw Material | 45 | 80 | 140 | 285 | 425 | 670 | 800 | |||
| a=12° | Cement | 70 | 120 | 205 | 455 | 685 | 1080 | 1295 | ||
| Raw Material | 50 | 95 | 165 | 340 | 510 | 805 | 960 | |||
| Length | Standard | mm | 2000 | |||||||
| Off Standard | mm | 2500 | ||||||||
| Air Pressure | KPa | 4-5.5 | ||||||||
| Air Volume | m3/m2.min | 1.5-2 | ||||||||
| Fabric Layer | Material | Synthetic Fiber | ||||||||
| Thickness | mm | 4~6 | ||||||||
| Temp | ℃ | 150 | ||||||||
| Radial Breaking Strength | N/cm | 4700 | ||||||||
| Resistance | Pa | 800-1200(2m3/m2/min) | ||||||||
| Conveying material: Dry powder materials with water content ≤1% and temperature≤150 ℃ | ||||||||||
